Description

This product is a 56k Data/Fax soft Modem which is support to ITU T V.92. It adoptes the technology of Smartlink Modem, and we optimize it based on the condition of China. This Modem can be used in the following Operating System: Windows98, Windows ME, Windows NT, Windows 2000 Windows XP, VISTA, WIN7 and Linux. And you can operation this Modem by using Hyper Terminal. This Modem can prevent surge-damaged, and it has got the authentication of China Compulsory Certification (3C), FCC and CE, you can use it safely and stably.

Features

• Chipset: Smartlink 2801
• Data modulation rate: V.34bis, V.34+, ITU-T V.34, V.32bis, V.32, V.22bis, V.22 and Bell 212A, ITU-T V.23, V.21 and Bell 103
• Transmission: 56,000, 33,600, 31,200, 28,800, 24,000, 14,400, 12,000, 9,600, 7,200, 4,800, 1,200, 1,200/75 and 300bps
• Voice mode: remote, local record and play back voice
• Computer interface: PCI bus and plug-and-play
• Data compression: ITU-T V.42bis and MNP 5
• Error correction: ITU-T V.42 and MNP 2, 3, and 4
• Commands: extended AT command set
• Test modes: analog, digital and remote digital loopback with self-test
• Compatibility: Pentium 200(over) with MMX, CPU with PCI bus
• Auto-dialing: touch-tone and pulse dialing, auto dial and answer
• Fully compliant with V.90, V.34bis, V.32, V.32 and V.22bis specifications
• Compatible with Windows 95, 98, 2000, XP, ME and NT4.0 operating systems and most PCI bus compatible systems
• Software upgradeable
• Supports variable sample rates via the SLOTREQ protocol and valid tag bits
• Low latency GPIO data transfer
• Supports modem wake-up on ring from D3 cold
• Advanced power management support
• PPMI (PCI: Power Management Interface)

Specification



Operating Temperature	0℃ ~40℃
Storage Temperature	-40 ℃~70℃
Operating Humidity	10%~90% RH no condensing
Product Highlight	Conveniently check the connection records by detailed syslog
Operation System	Supports Windows95, Windows98, Windows ME, Windows NT, Windows XP, Windows2000, Windows vista, windows 7 and Linux

Requirements

Package Contents

• 56K PCI MODEM
• CD Driver
• Manual
• Color Box(Optional)
